Gripping force (per jaw) 6-15 N

Stroke 7 mm

Recommended workpiece weight 0.25 kg

Opening/Closing time 0.15 s / 0.15 s

Noise emission ＜ 50 dB

Weight 0.15 kg

Driving method Precise planetary gears + Rack and pinion

Size 85.6 mm x 38 mm x 23.2mm

Communication interface Modbus RTU (RS485), Digital I/O

Rated voltage 24 V DC ± 10%

Rated current 0.15 A

Peak current 0.8 A

IP class IP 40

Recommended environment 0~40°C, under 85% RH

Certification CE，FCC，RoHS
